Your laser bed, on a grid.
A precision alignment grid generated for your exact machine. Burn it onto scrap cardboard once — place every blank perfectly, forever.
Free download
50 Laser Hacks — the free guide
50 field-tested tricks for cleaner cuts, faster jobs, and fewer ruined blanks. Grab it free — no purchase needed.
What's in the file
Three layers, zero guesswork
GRID_LINES
10mm reference grid
Hairline lines every 10mm, built to score at low power. Your permanent coordinate system, burned right onto scrap cardboard.
CENTER_CROSSHAIR
Center crosshair
Heavier full-length axis lines through dead center of your bed. Your primary alignment reference for centering any blank.
FRAME_BORDER
Outer frame border
A cut line at your exact bed dimensions. Trim the cardboard flush, or leave the layer off — your call.
New — Material Library
Stop guessing settings. Burn the right test.
Tell us your laser and wattage — get a LightBurn material library (.clb) with engrave and cut settings for 14 materials, plus open-and-burn test files where every cell is already configured and bracketed around the predicted sweet spot for your machine. No more 0–100% sweeps wasting material.
.CLB LIBRARY
Import once — every material in LightBurn's picker, scaled to your watts
BURN TESTS
Pre-assigned layers for engrave + cut tests — open, burn, pick your winner
SETTINGS PDF
Printable chart of every number, plus the never-laser safety list
Process
How it works
01
Pick your machine
40+ lasers in the database — Glowforge, xTool, OMTech, Thunder, and more. Or punch in custom dimensions.
02
Download your files
SVG + DXF sized to your exact bed, with the correct origin corner baked in. Plus a quick start guide.
03
Burn it onto cardboard
Low power, high speed, one pass. Pin scrap cardboard to your bed and score the grid into it.
04
Place blanks with confidence
Drop any blank on the grid and read its exact position. No more eyeballing, no more ruined material.
Coverage
Sized to your machine — not close enough
Popular bed sizes below, but the generator builds your grid at your exact dimensions — 40+ machines in the database plus fully custom sizes up to 1500mm.
Pricing
One-time payment. Lifetime access.
Buy once, generate files for every machine you own, forever. Lost your link? We re-send it any time.
Grid Generator
$9
Precision alignment grid sized to your exact bed. SVG + DXF.
- ✓ 40+ machine database
- ✓ Custom bed sizes
- ✓ Correct origin corner baked in
Material Library
$29
LightBurn settings library + burn tests scaled to your laser’s power.
- ✓ 14 materials, engrave + cut
- ✓ Open-and-burn .lbrn2 tests
- ✓ .clb library + settings PDF
Most popular
Bundle
$27
Save 31%Both tools. Everything scaled to your machine.
- ✓ Grid Generator
- ✓ Material Library
- ✓ Save 31% vs buying separately
Stop eyeballing. Start aligning.
Grid + material library, built for your exact machine. Instant download.
Get the Bundle — $27 →
